E28 electric actuator is the electric actuator of the branch valve, small valve and dynamic balance valve of the water collector. It is the electric drive part of the control valve. It is applicable to the switch of small valve or the execution control of PDM. It is the dual position and stable control of the closed loop valve of the water heating system or central air-conditioning water system. In the water heating system, it is directly installed on the water return pipe or thermostatic valve body of the water heater. The valve will automatically close after the normally open actuator is energized, and the valve will automatically open after the normally closed electric actuator is energized.

Product features

Paraffin thruster, driven by PTC heating
With spring return function
Mute setting, no noise during operation
The nut connection is adopted, and the installation mode is simple and the quick disassembly is convenient

Technical Parameter

• Voltage: AC220V / 230V / 110V / 24V
• Power waste: 3.5VA
• Thrust: 110N
• Trip: > 3.0mm
• Whole journey time: 6min
• Coupling nut: M30 x 1.5
• Ambient temperature: -5 ～ 60℃
• Leader length: 900mm
• Shell material: flame-retardant ABS+PC (interior is flame-retardant reinforced PA66)
• Protection grade:IP54
